Marble tang sight winchester installation.

Place peep tang sight on tang so that when looking through peep sight aperture all sights are in alignment. Author s newly acquired winchester model 1894 chief crazy horse commemorative rifle in 38 55 with marble s tang sight installed. Marbles tang sight f winchester 9422 22 magnum. For the full length version of this and other midwayusa videos visit the midwayusa video library.

These highly precision cnc machined parts match up every time for repeatability. Adjust peep tang sight so that you are in the middle of the adjustment windage and elevation. Marble s tang sight adds a great deal to the practical accuracy of the model 94 chief crazy horse commemorative without detracting from the classic lines of the gun. This sight base has a 1 125 hole spacing which will fit marlin model 36a.

Marble arms company s tang sight for the winchester model 1894 shown with screws and extra apertures. Very rare lyman 15 tang sight for winchester mounting holes are 2 175 inches apart center to center the code is difficult to read it could be an i for the winchester 1876 this it what i believe it s coded for but based on the position of the staff on the base it would also fit the 1894 and 1892 sight has a very nice plum blue coverage sight elevation works smooth the windage works fine but gets somewhat tight on the extremes. Adjust peep tang sight so that you are in the middle of the adjustment windage and elevation. Place peep tang sight on tang so that when looking through peep sight aperture all sights are in alignment.

A longer sight post may have to be installed for the 36a. Installation of the new peep sight was simply a matter of removing the plug screws from the rifle s tang and screwing down the marble s rear sight. The sight base remains mounted to the tang as before and with a twist of the setscrew the post is removed. For rifles that must be drilled and tapped to receive a tang sight complete mounting instructions are available on the marble s web site.

Tang peep sight installation 1. Sight in gun with factory sights to 100 yards. Select the post height that you want and press the post into place firmly then tighten the setscrew. Mark the holes 009800 hole spacing is 2 185 center to center.

It works perfectly with the stock front sight.
